HLMP-BD06-P00DD
LED RED CLEAR T/HManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited HLMP-BD06-P00DD is a red, clear lens, through-hole mounted LED. This discrete component features a dominant wavelength of 630nm and a peak wavelength of 639nm, with a typical forward voltage of 2V at 20mA test current. The oval-shaped lens, measuring 5.00mm, provides a clear viewing window for the red light emission. It is designed for applications requiring reliable visual indication, commonly found in industrial control systems, medical equipment, and consumer electronics. The component is supplied in Cut Tape (CT) packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Cut Tape (CT) |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 880mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2V |
| Lens Color | Red |
| Current - Test | 20mA |
| Viewing Angle | 70°, 35° |
| Height (Max) | 8.91mm |
| Wavelength - Peak | 639nm |
| Wavelength - Dominant | 630nm |
| Lens Transparency | Clear |
| Lens Style | Oval with Domed Top |
| Lens Size | 5.00mm |
