HLMP-4101
LED RED CLEAR T-1 3/4 T/HManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited HLMP-4101 is a red, diffused LED with a peak wavelength of 650nm and a dominant wavelength of 642nm. This through-hole component, packaged in a T-1 3/4 radial configuration, offers a luminous intensity of 1000mcd at a typical forward voltage of 1.8V and a test current of 20mA. The clear, colorless lens with a domed top and a narrow 8° viewing angle makes it suitable for precise indication applications. Common in industrial control systems, telecommunications equipment, and automotive lighting, this discrete LED is supplied in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 1000mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 1.8V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 8° |
| Height (Max) | 12.44mm |
| Wavelength - Peak | 650nm |
| Wavelength - Dominant | 642nm |
| Supplier Device Package | T-1 3/4 |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
