HLMA-QJ00-S0011
LED ORANGE CLEAR SMDManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Orange 605nm LED Indication - Discrete 1.9V 2-SMD, Flat Leads
Additional Information
Series: HLMA-Qx00RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-SMD, Flat Leads |
| Color | Orange |
| Size / Dimension | 2.09mm L x 2.92mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 500mcd |
| Configuration | - |
| Voltage - Forward (Vf) (Typ) | 1.9V |
| Lens Color | - |
| Current - Test | 20mA |
| Viewing Angle | 15° |
| Height (Max) | 2.92mm |
| Wavelength - Peak | 609nm |
| Wavelength - Dominant | 605nm |
| Supplier Device Package | SMD |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 1.91mm Dia |
