ASMT-TGBM-NT7B2
LED GREEN CLEAR 2MINIPLCC SMDManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited ASMT-TGBM-NT7B2 is a green 522nm LED in a 2-Mini PLCC surface mount package. This component offers a typical forward voltage of 3.3V and a peak wavelength of 516nm, producing a dominant wavelength of 522nm. The clear, colorless lens has a flat top with dimensions of 1.50mm L x 1.00mm W, contributing to a 120° viewing angle. It is rated at 480mcd with a test current of 20mA. The ASMT-TGBM series LED is supplied in Tape & Reel (TR) packaging and is utilized in various industrial applications for indication purposes. Its dimensions are 2.00mm L x 1.40mm W with a maximum height of 1.50mm.
Additional Information
Series: ASMT-TGBMRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-Mini PLCC |
| Color | Green |
| Size / Dimension | 2.00mm L x 1.40mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 480mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.3V |
| Lens Color | Colorless |
| Current - Test | 20mA |
| Viewing Angle | 120° |
| Height (Max) | 1.50mm |
| Wavelength - Peak | 516nm |
| Wavelength - Dominant | 522nm |
| Supplier Device Package | 2-MiniPLCC |
| Lens Transparency | Clear |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.50mm x 1.00mm |
