ASMT-CB20
LED BLUE CHIP SMDManufacturer: Broadcom Limited
Categories: LED Indication - Discrete
Quality Control: Learn More
Broadcom Limited ASMT-CB20 is a blue surface-mount LED indication component. This 0603 (1608 Metric) package features a discrete blue LED with a dominant wavelength of 470nm and a typical forward voltage of 2.85V at 10mA test current. The component has a millicandela rating of 25mcd and a wide viewing angle of 150°. Its dimensions are 1.60mm L x 0.80mm W with a maximum height of 0.30mm. The LED is supplied in Tape & Reel (TR) packaging. This component is utilized in industrial automation, medical devices, and consumer electronics for indicator functions.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 0603 (1608 Metric) |
| Color | Blue |
| Size / Dimension | 1.60mm L x 0.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 25mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.85V |
| Lens Color | - |
| Current - Test | 10mA |
| Viewing Angle | 150° |
| Height (Max) | 0.30mm |
| Wavelength - Peak | 468nm |
| Wavelength - Dominant | 470nm |
| Supplier Device Package | Chip LED |
| Lens Transparency | - |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 1.60mm x 0.80mm |
