ASMT-QHB2-FEF0E
LED RED 618NM 4PLCCManufacturer: Broadcom Limited
Categories: LED Color Lighting
Quality Control: Learn More
Broadcom Limited ASMT-QHB2-FEF0E is a red LED with a peak wavelength of 618nm (611nm to 625nm). This surface mount component utilizes a 4-PLCC package with dimensions of 3.20mm x 2.80mm and a seated height of 2.10mm. It operates with a typical forward voltage of 2.7V and can handle a maximum continuous current of 150mA. Under test conditions at 25°C and 150mA, it provides a luminous flux of 16 lumens (12lm to 20lm) and an efficacy of 40 lm/W. The viewing angle is 120°. This LED is commonly found in automotive lighting, general lighting, and industrial applications. It is supplied on a tape and reel.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-PLCC |
| Color | Red |
| Wavelength | 618nm (611nm ~ 625nm) |
| Size / Dimension | 0.126"" L x 0.110"" W (3.20mm x 2.80mm) |
| Mounting Type | Surface Mount |
| Voltage - Forward (Vf) (Typ) | 2.7V |
| Current - Test | 150mA |
| Viewing Angle | 120° |
| Current - Max | 150mA |
| Supplier Device Package | 4-PLCC |
| Lumens/Watt @ Current - Test | 40 lm/W |
| Height - Seated (Max) | 0.083"" (2.10mm) |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 16lm (12lm ~ 20lm) |
