HDSP-5607
DISP 7SEG 0.56"" OV/FL GRN 10DIPManufacturer: Broadcom Limited
Categories: LED Character and Numeric
Quality Control: Learn More
Broadcom Limited HDSP-560x series HDSP-5607 is a 0.56-inch green 7-segment display module featuring a +/-1 overflow character. This common anode component operates with a typical forward voltage of 2.1V and a test current of 10mA, dissipating a maximum of 105mW. The display measures 0.670 inches high by 0.495 inches wide by 0.315 inches deep (17.02mm x 12.57mm x 8.00mm). It is housed in a 10-DIP (0.600", 15.24mm) package with 9 leads and a peak wavelength of 566nm. This display is commonly utilized in instrumentation, industrial controls, and point-of-sale systems.
Additional Information
Series: HDSP-560xRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 10-DIP (0.600"", 15.24mm), 9 Leads |
| Color | Green |
| Display Type | 7-Segment |
| Size / Dimension | 0.670"" H x 0.495"" W x 0.315"" D (17.02mm x 12.57mm x 8.00mm) |
| Number of Characters | +/-1 (overflow) |
| Millicandela Rating | 2.5mcd |
| Common Pin | Common Anode |
| Digit/Alpha Size | 0.56"" (14.22mm) |
| Voltage - Forward (Vf) (Typ) | 2.1V |
| Current - Test | 10mA |
| Wavelength - Peak | 566nm |
| Power Dissipation (Max) | 105mW |
