HDSM-531C
DISPLAY 7SEG 0.56"" SGL RED 10SMDManufacturer: Broadcom Limited
Categories: LED Character and Numeric
Quality Control: Learn More
Broadcom Limited HDSM-531C is a single-digit, 0.56-inch red 7-segment display module. This component features a common anode configuration and operates with a typical forward voltage of 2V and a test current of 20mA, yielding a millicandela rating of 16mcd. The display's physical dimensions are 0.669 inches high by 0.492 inches wide by 0.148 inches deep (17.00mm x 12.50mm x 3.75mm). Packaged in a 10-SMD, No Lead format and supplied on Tape & Reel (TR), this display is suitable for applications in industrial control, instrumentation, and point-of-sale systems. Its peak wavelength is 632nm, and it has a maximum power dissipation of 65mW.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 28 week(s)Product Status: ActivePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 10-SMD, No Lead |
| Color | Red |
| Display Type | 7-Segment |
| Size / Dimension | 0.669"" H x 0.492"" W x 0.148"" D (17.00mm x 12.50mm x 3.75mm) |
| Number of Characters | 1 |
| Millicandela Rating | 16mcd |
| Common Pin | Common Anode |
| Digit/Alpha Size | 0.56"" (14.22mm) |
| Voltage - Forward (Vf) (Typ) | 2V |
| Current - Test | 20mA |
| Wavelength - Peak | 632nm |
| Power Dissipation (Max) | 65mW |
