AS33-M50M-S74
33MM MOD 50B MT 7V M4 HUB SSIManufacturer: Broadcom Limited
Categories: Industrial
Quality Control: Learn More
Broadcom Limited AS33-M50M-S74 is a magnetic encoder component featuring a 33mm module size and 50-bit magnetic encoding. This Series AS33-M50M device utilizes an external magnet (not included) for actuation and offers an SSI output for high-precision digital data transmission. Designed for robust operation, it has a voltage supply range of 7V to 12.5V. The AS33-M50M-S74 is suitable for demanding industrial applications, including motor control and automation systems, where precise position feedback is critical. Its chassis mount configuration and vertical orientation facilitate integration into various electromechanical assemblies. The component is supplied in tray packaging.
Additional Information
Series: AS33-M50MRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Output Type | SSI |
| Mounting Type | Chassis Mount, Motors |
| Orientation | Vertical |
| Termination Style | Connector |
| Voltage - Supply | 7V ~ 12.5V |
| Encoder Type | Magnetic |
| Detent | No |
| Pulses per Revolution | - |
| Actuator Type | External Magnet, Not Included |
| Built in Switch | No |
| Rotational Life (Cycles Min) | - |
