AS22-M530-5T12
ROTARY ENCODR INCREMENT 2000PPRManufacturer: Broadcom Limited
Categories: Industrial
Quality Control: Learn More
The Broadcom Limited AS22-M530-5T12 is an incremental rotary encoder from the AS22 series, providing 2000 pulses per revolution. This chassis-mount component features a hole for shaft actuation and a user-selectable orientation, offering flexibility in system integration. It utilizes differential voltage output for robust signal transmission. Designed for industrial applications, this encoder is supplied in bulk packaging and terminates via a connector. The voltage supply range for this component is 4.5V to 5.5V.
Additional Information
Series: AS22RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Output Type | Differential Voltage |
| Mounting Type | Chassis Mount |
| Orientation | User Selectable |
| Termination Style | Connector |
| Voltage - Supply | 4.5V ~ 5.5V |
| Encoder Type | Incremental |
| Detent | No |
| Pulses per Revolution | 2000 |
| Actuator Type | Hole for Shaft |
| Built in Switch | No |
| Rotational Life (Cycles Min) | - |
