AEDB-9140-A14
ROTARY ENCODER OPTICAL 500PPRManufacturer: Broadcom Limited
Categories: Encoders
Quality Control: Learn More
Broadcom Limited AEDB-9140-A14 is an optical rotary encoder from the AEDB-9140 series. This incremental encoder offers 500 pulses per revolution with quadrature and index output. It features a 5mm open center actuator and is designed for chassis and motor mounting. The device utilizes terminal pins for termination and operates on a 5V supply. This component is suitable for applications in industrial automation, robotics, and motor control systems where precise rotational feedback is critical.
Additional Information
Series: AEDB-9140RoHS Status: ROHS3 CompliantManufacturer Lead Time: 16 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Output Type | Quadrature with Index (Incremental) |
| Mounting Type | Chassis Mount, Motors |
| Orientation | - |
| Termination Style | Terminal Pins |
| Voltage - Supply | 5V |
| Encoder Type | Optical |
| Detent | No |
| Pulses per Revolution | 500 |
| Actuator Type | 5mm Open Center |
| Built in Switch | No |
| Rotational Life (Cycles Min) | - |
| Programmable | Not Verified |
