AEAT-6600-T16
ROTARY ENCODER MAGNETICManufacturer: Broadcom Limited
Categories: Encoders
Quality Control: Learn More
Broadcom Limited AEAT-6000-T16 Magnetic Rotary Encoder. This incremental encoder provides quadrature outputs, enabling precise angular position sensing through an external magnetic field. Designed for surface mount applications, it features an SMD (SMT) tab termination style. The device supports dual supply voltage ranges: 3V to 3.6V and 4.5V to 5.5V. Its robust magnetic sensing technology makes it suitable for applications in industrial automation, robotics, and automotive systems where accurate non-contact rotational feedback is critical. The AEAT-6000-T16 is provided in bulk packaging.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 26 week(s)Product Status: ActivePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Output Type | Quadrature (Incremental) |
| Mounting Type | Surface Mount |
| Orientation | - |
| Termination Style | SMD (SMT) Tab |
| Voltage - Supply | 3V ~ 3.6V, 4.5V ~ 5.5V |
| Encoder Type | Magnetic |
| Detent | No |
| Pulses per Revolution | - |
| Actuator Type | External Magnet, Not Included |
| Built in Switch | No |
| Rotational Life (Cycles Min) | - |
| Programmable | Not Verified |
