HLCP-F100
LIGHT BAR 0.8X0.4"" ALGAAS DUALManufacturer: Broadcom Limited
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
Broadcom Limited HLCP-F100 is a dual-element LED indicator bar, featuring two high-efficiency AlGaAs red LED chips. This through-hole component is designed for direct mounting on printed circuit boards and offers a distinctive rectangular lens with a flat top for clear visual indication. Each LED in the bar is rated for 1.8V and a forward current of 20mA, with a typical luminous intensity of 15mcd at its peak wavelength of 645nm. The DIP package configuration ensures straightforward insertion and soldering. The HLCP-F100 is commonly utilized in industrial control systems, instrumentation, and consumer electronics where reliable visual status feedback is critical.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Current | 20mA |
| Color | Red (x 2) |
| Voltage Rating | 1.8V |
| Mounting Type | Through Hole |
| Millicandela Rating | 15mcd |
| Configuration | Bar - 2 High, DIP |
| Viewing Angle | - |
| Lens Type | - |
| Wavelength - Peak | 645nm |
| Lens Style | Rectangle with Flat Top |
| Lens Size | - |
