AT-41533-TR2G
RF TRANS NPN 12V SOT23Manufacturer: Broadcom Limited
Categories: Bipolar RF Transistors
Quality Control: Learn More
Broadcom Limited AT-41533-TR2G is an NPN bipolar RF transistor designed for high-frequency applications. This surface-mount component, housed in a SOT-23 package, operates with a collector-emitter breakdown voltage of 12V and a maximum collector current of 50mA. It delivers a typical gain range of 9dB to 14.5dB and features a low noise figure, with typical values between 1dB and 1.6dB across the 900MHz to 2.4GHz spectrum. The transistor is rated for a maximum power dissipation of 225mW and an operating junction temperature of 150°C. This device is commonly utilized in wireless communications infrastructure, satellite communications, and defense systems. The AT-41533-TR2G is supplied in Tape & Reel packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-236-3, SC-59, SOT-23-3 |
| Mounting Type | Surface Mount |
| Transistor Type | NPN |
| Operating Temperature | 150°C (TJ) |
| Gain | 9dB ~ 14.5dB |
| Power - Max | 225mW |
| Current - Collector (Ic) (Max) | 50mA |
| Voltage - Collector Emitter Breakdown (Max) | 12V |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 30 @ 5mA, 5V |
| Frequency - Transition | - |
| Noise Figure (dB Typ @ f) | 1dB ~ 1.6dB @ 900MHz ~ 2.4GHz |
| Supplier Device Package | SOT-23 |
