FT932Q-T
IC MCU 32BIT 128KB FLASH 48QFNManufacturer: Bridgetek Pte Ltd.
Categories: Microcontrollers
Quality Control: Learn More
Bridgetek Pte Ltd. FT932Q-T is a 32-bit microcontroller featuring the FT32 single-core processor operating at 100MHz. This component offers 128KB of FLASH program memory and 32KB of RAM. Connectivity options include I2C, SD, SPI, UART/USART, and USB interfaces. It incorporates 3x 10-bit Analog-to-Digital converters and 2x 10-bit Digital-to-Analog converters. The FT932Q-T is housed in a 48-QFN (7x7) surface mount package with 40 I/O pins. Integrated peripherals include Power-On Reset (POR), Pulse Width Modulation (PWM), and Watchdog Timer (WDT). The operating temperature range is -40°C to 85°C. This device is suitable for applications in industrial automation, consumer electronics, and IoT devices.
Additional Information
Series: FT93xRoHS Status: RoHS CompliantManufacturer Lead Time: 34 week(s)Product Status: ActivePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 48-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Speed | 100MHz |
| Program Memory Size | 128KB (128K x 8) |
| RAM Size | 32K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | FT32 |
| Data Converters | A/D 3x10b; D/A 2x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 2.97V ~ 3.63V |
| Connectivity | I2C, SD, SPI, UART/USART, USB |
| Peripherals | POR, PWM, WDT |
| Supplier Device Package | 48-QFN (7x7) |
| Number of I/O | 40 |
| Programmable | Not Verified |
