OLMA-50C000-A01A-AA000
LED MOD OLM COOL WHT RECT 5000KManufacturer: Bridgelux
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Bridgelux OLM™ series LED Module, part number OLMA-50C000-A01A-AA000, features a cool white, 5000K color temperature with a 70 CRI. This rectangular module is designed for applications requiring high luminous flux, delivering 2144 lumens typical at 350mA test current, with an efficiency of 116 lm/W at 70°C. It operates with a forward voltage of 53V and has a maximum current rating of 700mA. The module includes a connector for ease of integration and measures 164.00mm in length by 73.00mm in width, with a height of 27.00mm. This component is suitable for use in general lighting and architectural lighting applications. It is supplied in tray packaging.
Additional Information
Series: OLM™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Cool |
| Wavelength | - |
| Size / Dimension | 164.00mm L x 73.00mm W |
| Type | LED Module |
| Configuration | Rectangle |
| Voltage - Forward (Vf) (Typ) | 53V |
| Height | 27.00mm |
| Current - Test | 350mA |
| Viewing Angle | - |
| Lens Type | - |
| Current - Max | 700mA |
| Lumens/Watt @ Current - Test | 116 lm/W |
| CCT (K) | 5000K |
| CRI (Color Rendering Index) | 70 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 70°C |
| Luminous Flux @ Current/Temperature | 2144lm (Typ) |
