OLMA-40E000-A01A-AA000
LED MOD OLM NEUT WHT RECT 4000KManufacturer: Bridgelux
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
The Bridgelux OLM™ OLMA-40E000-A01A-AA000 is a neutral white, rectangular LED module with a color temperature of 4000K. This component offers a typical luminous flux of 2022 lumens at 350mA test current, achieving 109 lm/W. It operates with a forward voltage of 53V (typical) and a maximum current of 700mA, with a test current of 350mA. The module features a Color Rendering Index (CRI) of 80 and is supplied in tray packaging. Its dimensions are 164.00mm in length by 73.00mm in width, with a height of 27.00mm. This LED module is well-suited for general lighting applications, including commercial and industrial environments, where consistent color and high energy efficiency are paramount. It includes an integrated connector for ease of implementation.
Additional Information
Series: OLM™RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Connector |
| Packaging | Tray |
| Color | White, Neutral |
| Wavelength | - |
| Size / Dimension | 164.00mm L x 73.00mm W |
| Type | LED Module |
| Configuration | Rectangle |
| Voltage - Forward (Vf) (Typ) | 53V |
| Height | 27.00mm |
| Current - Test | 350mA |
| Viewing Angle | - |
| Lens Type | - |
| Current - Max | 700mA |
| Lumens/Watt @ Current - Test | 109 lm/W |
| CCT (K) | 4000K |
| CRI (Color Rendering Index) | 80 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 70°C |
| Luminous Flux @ Current/Temperature | 2022lm (Typ) |
