BXRV-TR-1830G-10A0-B-25-S2
LED COB VESTA WM WH ROUND 1800KManufacturer: Bridgelux
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
LED Lighting COBs Engines Modules Chip On Board (COB) Vesta™ SE Tunable White Gen 2 White, Warm Round
Additional Information
Series: Vesta™ SE Tunable White Gen 2RoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: Last Time BuyPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | With Holder |
| Packaging | Tray |
| Color | White, Warm |
| Wavelength | - |
| Size / Dimension | 36.20mm Dia |
| Type | Chip On Board (COB) |
| Configuration | Round |
| Voltage - Forward (Vf) (Typ) | 34.8V |
| Height | 3.80mm |
| Current - Test | 250mA |
| Viewing Angle | 130° |
| Lens Type | Flat |
| Current - Max | 480mA |
| Lumens/Watt @ Current - Test | 113 lm/W |
| CCT (K) | 1800K 5-Step MacAdam Ellipse, 3000K 3-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 90 |
| Light Emitting Surface (LES) | 10.30mm Dia |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 980lm |
