BXRA-56C5300-H-04
LED COB RS COOL WHT SQUARE 5600KManufacturer: Bridgelux
Categories: LED COBs, Engines, Modules, Strips
Quality Control: Learn More
Bridgelux BXRA-56C5300-H-04 is a high-performance Chip On Board (COB) LED from the RS series. This cool white emitter features a square light-emitting surface (LES) with a correlated color temperature (CCT) of 5600K, specified within a 4-step MacAdam ellipse for tight color consistency. Designed for demanding illumination applications, it delivers a typical luminous flux of 6300 lumens at 2.1A test current, with a luminous efficacy of 128 lm/W at 25°C. The component has a forward voltage of 23.5V and a maximum drive current of 2.8A. With a Color Rendering Index (CRI) of 70 and a 120° viewing angle, this Bridgelux COB is suitable for general lighting, architectural lighting, and display applications where accurate color representation and uniform light distribution are critical. The module measures 45.60mm L x 50.80mm W with a height of 3.00mm.
Additional Information
Series: RSRoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Color | White, Cool |
| Wavelength | - |
| Size / Dimension | 45.60mm L x 50.80mm W |
| Type | Chip On Board (COB) |
| Configuration | Square |
| Voltage - Forward (Vf) (Typ) | 23.5V |
| Height | 3.00mm |
| Current - Test | 2.1A |
| Viewing Angle | 120° |
| Lens Type | Domed |
| Current - Max | 2.8A |
| Lumens/Watt @ Current - Test | 128 lm/W |
| CCT (K) | 5600K 4-Step MacAdam Ellipse |
| CRI (Color Rendering Index) | 70 |
| Light Emitting Surface (LES) | - |
| Temperature - Test | 25°C |
| Luminous Flux @ Current/Temperature | 6300lm (Typ) |
