CD214C-F350
DIODE GEN PURP 50V 3A SMCManufacturer: Bourns Inc.
Categories: Single Diodes
Quality Control: Learn More
Bourns Inc. CD214C-F350 is a general-purpose diode designed for robust performance in demanding applications. This device features a 50V reverse voltage rating and a 3A average rectified forward current capability. Engineered with a fast recovery time of 25 ns, it is suitable for switching speeds up to 200mA (Io). Key electrical specifications include a forward voltage drop of 920 mV at 3A and a low reverse leakage current of 10 µA at 50V. The diode exhibits a capacitance of 45pF at 4V and 1MHz. Housed in an SMC (DO-214AB) package, the CD214C-F350 is supplied on tape and reel for efficient automated assembly. This component is ideal for use in power supply circuits, signal conditioning, and general rectification across various industrial electronics sectors. Its operating junction temperature range is -55°C to 150°C.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | DO-214AB, SMC |
| Mounting Type | Surface Mount |
| Speed | Fast Recovery =< 500ns, > 200mA (Io) |
| Reverse Recovery Time (trr) | 25 ns |
| Technology | Standard |
| Capacitance @ Vr, F | 45pF @ 4V, 1MHz |
| Current - Average Rectified (Io) | 3A |
| Supplier Device Package | SMC (DO-214AB) |
| Operating Temperature - Junction | -55°C ~ 150°C |
| Voltage - DC Reverse (Vr) (Max) | 50 V |
| Voltage - Forward (Vf) (Max) @ If | 920 mV @ 3 A |
| Current - Reverse Leakage @ Vr | 10 µA @ 50 V |
