CD1206-S01575

Banner
productimage

CD1206-S01575

DIODE GEN PURP 100V 150MA 1206

Manufacturer: Bourns Inc.

Categories: Single Diodes

Quality Control: Learn More

Bourns Inc. CD1206-S01575 is a general-purpose diode designed for surface-mount applications. This component features a maximum DC reverse voltage (Vr) of 100V and an average rectified forward current (Io) of 150mA. The forward voltage (Vf) is rated at 1V maximum at 50mA. With a reverse leakage current of 2.5 µA at 100V and a swift 4 ns reverse recovery time, this diode is suitable for signal rectification and switching applications. It exhibits a capacitance of 3pF at 0V and 100MHz. The device is packaged in a 1206 (3216 Metric) footprint and supplied on tape and reel. Operating temperature ranges from -55°C to 125°C. This component finds utility in various electronic systems, including power supplies, signal processing, and telecommunications infrastructure.

Additional Information

Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)
Technical Details:
PackagingTape & Reel (TR)
Package / Case1206 (3216 Metric)
Mounting TypeSurface Mount
SpeedSmall Signal =< 200mA (Io), Any Speed
Reverse Recovery Time (trr)4 ns
TechnologyStandard
Capacitance @ Vr, F3pF @ 0V, 100MHz
Current - Average Rectified (Io)150mA
Supplier Device Package1206
Operating Temperature - Junction-55°C ~ 125°C
Voltage - DC Reverse (Vr) (Max)100 V
Voltage - Forward (Vf) (Max) @ If1 V @ 50 mA
Current - Reverse Leakage @ Vr2.5 µA @ 100 V
