PM5-PBWDW12.0
PNL MNT W/ WIRE 430NM 200MCD BLUManufacturer: Bivar Inc.
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Bivar Inc. PM5 series LED Panel Indicator, part number PM5-PBWDW12-0, is a diffused blue LED with a 120° viewing angle and a millicandela rating of 200mcd at a peak wavelength of 430nm. This component is designed for panel mounting with a 0.39" (9.91mm) round cutout and features 12" (304.80mm) wire leads for termination. It operates across a wide voltage range of 8V to 48V and draws a current of 20mA. The white diffused lens and IP67 ingress protection make it suitable for demanding industrial environments, including automation and control systems.
Additional Information
Series: PM5RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bag |
| Current | 20mA |
| Voltage | 8V ~ 48V |
| Type | LED |
| Millicandela Rating | 200mcd |
| Termination Style | Wire Leads - 12"" (304.80mm) |
| Lens Color | White |
| Viewing Angle | 120° |
| Ingress Protection | IP67 |
| Ratings | AC/DC |
| Panel Cutout Dimensions | 0.39"" (9.91mm) |
| Wavelength - Peak | 430nm |
| Lens Transparency | Diffused |
| Lamp Color | Blue |
| Panel Cutout Shape | Round |
| Lens Style | Round with Flat Top |
| Lens Size | 9.70mm Dia |
