PM5-KHD
PNL MNT 625NM 25MCD 2V REDManufacturer: Bivar Inc.
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Bivar Inc. PM5 Series LED Panel Indicator, Part Number PM5-KHD, offers a 625nm red diffused light source with a typical forward voltage of 2V and a maximum forward current of 20mA. This component features a 25mcd millicandela rating and a wide 120° viewing angle, housed within a round lens with a flat top, measuring 9.70mm in diameter. Designed for front-panel mounting, it requires a 0.39-inch (9.91mm) round panel cutout. This indicator is commonly utilized in industrial control, automation, and electronic equipment applications requiring clear visual status indication. The component is supplied in a bag.
Additional Information
Series: PM5RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bag |
| Current | 20mA |
| Voltage | 2V |
| Type | LED |
| Millicandela Rating | 25mcd |
| Termination Style | - |
| Lens Color | White |
| Viewing Angle | 120° |
| Ingress Protection | - |
| Ratings | Vf (Typ), If (Max) |
| Panel Cutout Dimensions | 0.39"" (9.91mm) |
| Wavelength - Peak | 625nm |
| Lens Transparency | Diffused |
| Lamp Color | Red |
| Panel Cutout Shape | Round |
| Lens Style | Round with Flat Top |
| Lens Size | 9.70mm Dia |
