PM3GD5VW6.0
LED ASSY PNL 3MM GRN DIFF 6Manufacturer: Bivar Inc.
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Bivar Inc. LED Panel Indicator, part number PM3GD5VW6-0, features a 3mm diffused green LED with a 35° viewing angle and a peak wavelength of 568nm. This component operates at 5V with a typical millicandela rating of 25mcd. Designed for panel mounting with a 0.16" (4.06mm) round cutout, it includes 6" (152.40mm) wire leads for termination. Its diffused lens provides a softer light output. Applications for this type of indicator are found in industrial control panels, medical equipment, and consumer electronics.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bag |
| Current | - |
| Voltage | 5V |
| Type | LED |
| Millicandela Rating | 25mcd |
| Termination Style | Wire Leads - 6"" (152.40mm) |
| Lens Color | - |
| Viewing Angle | 35° |
| Ingress Protection | - |
| Ratings | - |
| Panel Cutout Dimensions | 0.16"" (4.06mm) |
| Wavelength - Peak | 568nm |
| Lens Transparency | Diffused |
| Lamp Color | Green |
| Panel Cutout Shape | Round |
| Lens Style | Round with Domed Top |
| Lens Size | 3mm, T-1 |
