PM3-KHDW12.0
PNL MNT RED 20MA W/WIRE: 12Manufacturer: Bivar Inc.
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Bivar Inc. PM3 series LED panel indicator, part number PM3-KHDW12-0, offers a diffused red illumination with a 120° viewing angle. This component is designed for panel mounting with a 0.19" (4.83mm) round cutout. It features wire leads with a 12" (304.80mm) length for termination. The LED operates at a typical forward voltage of 2V and a maximum forward current of 20mA, producing a millicandela rating of 30mcd at a peak wavelength of 625nm. The lens is white, round with a flat top, and 5.90mm in diameter, providing diffused light output. This component is suitable for applications in industrial automation and control systems.
Additional Information
Series: PM3RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bag |
| Current | 20mA |
| Voltage | 2V |
| Type | LED |
| Millicandela Rating | 30mcd |
| Termination Style | Wire Leads - 12"" (304.80mm) |
| Lens Color | White |
| Viewing Angle | 120° |
| Ingress Protection | - |
| Ratings | Vf (Typ), If (Max) |
| Panel Cutout Dimensions | 0.19"" (4.83mm) |
| Wavelength - Peak | 625nm |
| Lens Transparency | Diffused |
| Lamp Color | Red |
| Panel Cutout Shape | Round |
| Lens Style | Round with Flat Top |
| Lens Size | 5.90mm Dia |
