PM3-KGDW12.0
PNL MNT GREEN 20MA W/WIRE: 12Manufacturer: Bivar Inc.
Categories: Panel Indicators, Pilot Lights
Quality Control: Learn More
Bivar Inc. PM3 Series LED Panel Indicator, part number PM3-KGDW12-0, is a green diffused indicator with a 120° viewing angle. This component features a 2.1V forward voltage and a maximum continuous forward current of 20mA, delivering a typical luminous intensity of 30mcd at 568nm peak wavelength. The indicator is designed for panel mounting with a 0.19-inch round cutout and includes 12-inch wire leads for termination. Its diffused lens, with a 5.90mm diameter, ensures uniform light distribution. This component is commonly employed in industrial automation, control panels, and equipment status indication.
Additional Information
Series: PM3RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDownload Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bag |
| Current | 20mA |
| Voltage | 2.1V |
| Type | LED |
| Millicandela Rating | 30mcd |
| Termination Style | Wire Leads - 12"" (304.80mm) |
| Lens Color | White |
| Viewing Angle | 120° |
| Ingress Protection | - |
| Ratings | Vf (Typ), If (Max) |
| Panel Cutout Dimensions | 0.19"" (4.83mm) |
| Wavelength - Peak | 568nm |
| Lens Transparency | Diffused |
| Lamp Color | Green |
| Panel Cutout Shape | Round |
| Lens Style | Round with Flat Top |
| Lens Size | 5.90mm Dia |
