SMP2-UWD
LED WHITE DIFFUSED 2PLCC SMDManufacturer: Bivar Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Bivar Inc. SMP2-UWD is a white diffused LED, presented in a 2-PLCC surface mount package. This component offers a typical forward voltage of 3.2V and an operating current of 20mA, delivering a luminous intensity of 1050mcd. The diffused lens style ensures a broad 120° viewing angle, making it suitable for general indication applications across various industries, including industrial automation and consumer electronics. The component is supplied on tape and reel for automated assembly processes. Its compact dimensions of 3.20mm L x 2.80mm W and a maximum height of 2.00mm facilitate integration into space-constrained designs.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 2-PLCC |
| Color | White |
| Size / Dimension | 3.20mm L x 2.80mm W |
| Mounting Type | Surface Mount |
| Millicandela Rating | 1050mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 3.2V |
| Lens Color | - |
| Current - Test | 20mA |
| Viewing Angle | 120° |
| Height (Max) | 2.00mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | - |
| Supplier Device Package | 2-PLCC |
| Lens Transparency | Diffused |
| Lens Style | Round with Flat Top |
| Lens Size | - |
