R50RB2-4-0045
LED BLUE/RED CLEAR T/HManufacturer: Bivar Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Blue, Red 465nm Blue, 628nm Red LED Indication - Discrete 3.8V Blue, 2.6V Red 4-DIP (0.200"", 5.08mm)
Additional Information
Series: Orca RRoHS Status: ROHS3 CompliantManufacturer Lead Time: 8 week(s)Product Status: ActivePackaging: TubeDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tube |
| Package / Case | 4-DIP (0.200"", 5.08mm) |
| Color | Blue, Red |
| Size / Dimension | 7.60mm L x 7.60mm W |
| Mounting Type | Through Hole |
| Millicandela Rating | 400mcd Blue, 4000mcd Red |
| Configuration | Common Cathode |
| Voltage - Forward (Vf) (Typ) | 3.8V Blue, 2.6V Red |
| Lens Color | Colorless |
| Current - Test | 50mA Blue, 50mA Red |
| Viewing Angle | 45° |
| Height (Max) | 7.80mm |
| Wavelength - Peak | - |
| Wavelength - Dominant | 465nm Blue, 628nm Red |
| Supplier Device Package | - |
| Lens Transparency | Clear |
| Lens Style | Round with Domed Top |
| Lens Size | 4.60mm Dia |
