R4PGD
LED GREEN DIFFUSED T/HManufacturer: Bivar Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
Bivar Inc. R4PGD is a green diffused, through-hole LED designed for general indication. This discrete component features a 2.2V forward voltage and a typical forward current of 20mA. The diffused lens provides a wide 120° viewing angle, ensuring broad visibility. Its rectangular lens measures 4.00mm x 2.00mm with a flat top and stands at a maximum height of 7.00mm. The R4PGD emits light with a peak wavelength of 555nm, offering a millicandela rating of 2mcd. This component is suitable for various industrial and consumer electronics applications requiring reliable visual feedback.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Green |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 2mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2.2V |
| Lens Color | Green |
| Current - Test | 20mA |
| Viewing Angle | 120° |
| Height (Max) | 7.00mm |
| Wavelength - Peak | 555nm |
| Wavelength - Dominant | - |
| Supplier Device Package | - |
| Lens Transparency | Diffused |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 4.00mm x 2.00mm |
