R3HD
LED RED DIFFUSED T/HManufacturer: Bivar Inc.
Categories: LED Indication - Discrete
Quality Control: Learn More
This Bivar Inc. through-hole LED, part number R3HD, provides red diffused light output. It features a standard radial package with a diffused red lens measuring 3.30mm x 1.90mm, offering a typically flat top rectangular profile. Operating at a forward voltage of 2V, this component is specified for a test current of 20mA, yielding a millicandela rating of 6mcd. The viewing angle is 100 degrees, with a peak wavelength of 625nm. This discrete indicator is commonly found in industrial control, automotive systems, and consumer electronics applications.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Bulk |
| Package / Case | Radial |
| Color | Red |
| Size / Dimension | - |
| Mounting Type | Through Hole |
| Millicandela Rating | 6mcd |
| Configuration | Standard |
| Voltage - Forward (Vf) (Typ) | 2V |
| Lens Color | Red |
| Current - Test | 20mA |
| Viewing Angle | 100° |
| Height (Max) | 4.00mm |
| Wavelength - Peak | 625nm |
| Wavelength - Dominant | - |
| Supplier Device Package | - |
| Lens Transparency | Diffused |
| Lens Style | Rectangle with Flat Top |
| Lens Size | 3.30mm x 1.90mm |
