LFR-255B48V
LED 5MM BLUE CLR 8-48V BA9SManufacturer: Bivar Inc.
Categories: Lamp Replacements
Quality Control: Learn More
The Bivar Inc. 255 series LFR-255B48V is a blue LED lamp replacement designed for miniature bayonet (BA9S) sockets. This component operates across a wide voltage range of 8 V to 48 V AC/DC, offering versatile power compatibility. With a typical forward voltage of 8V, it boasts a luminous intensity of 230mcd at a wavelength of 465nm. The physical dimensions are 0.413 inches in diameter by 1.024 inches in height (10.49mm x 26.01mm). This LED is suitable for applications requiring incandescent lamp replacements and indicator lights, often found in industrial control panels and general lighting systems. It is packaged in bags.
Additional Information
Series: 255RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BagDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bag |
| Color | Blue |
| Wavelength | 465nm |
| Size / Dimension | 0.413"" Dia x 1.024"" H (10.49mm x 26.01mm) |
| Millicandela Rating | 230mcd |
| Configuration | Single |
| Voltage - Forward (Vf) (Typ) | 8 V ~ 48 V AC/DC |
| Applications | Incandescent Replacements, Indicator Lights |
| Base Type | Miniature Bayonet (BA9S) |
| Can Replace Lamps | Multiple Miniature Bayonet Lamps |
