HT5-GRN-T
LED CBI 5MM GREEN SMD RA PC MNTManufacturer: Bivar Inc.
Categories: Circuit Board Indicators, Arrays, Light Bars, Bar Graphs
Quality Control: Learn More
Bivar Inc. presents the HT5-GRN-T, a single, 5mm T-1 3/4 surface mount, right-angle LED circuit board indicator. This component features a diffused, tinted, round with domed top lens style, providing a 45° viewing angle. Engineered for efficient illumination, it operates at a forward voltage of 2.1V and a forward current of 30mA, delivering a typical millicandela rating of 25mcd at a peak wavelength of 568nm. The HT5 series indicator is supplied on tape and reel for automated assembly processes. Its design is well-suited for applications in industrial control, medical equipment, and consumer electronics requiring reliable visual status indication.
Additional Information
Series: HT5RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Current | 30mA |
| Color | Green |
| Voltage Rating | 2.1V |
| Mounting Type | Surface Mount, Right Angle |
| Millicandela Rating | 25mcd |
| Configuration | Single |
| Viewing Angle | 45° |
| Lens Type | Diffused, Tinted |
| Wavelength - Peak | 568nm |
| Lens Style | Round with Domed Top |
| Lens Size | 5mm, T-1 3/4 |
