0833-2X4R-AY-F
CONN JACK 8PORT 1000 BASE-T PCBManufacturer: Bel Fuse Inc.
Categories: Modular Connector Jacks With Magnetics
Quality Control: Learn More
Bel Fuse Inc. 0833-2X4R-AY-F is an 8-port RJ45 modular connector jack designed for 10/100/1000 Base-T Ethernet applications. This component features a board edge, through-hole mounting type with a 90-degree (right) orientation. It supports AutoMDIX functionality and is shielded with an EMI finger for enhanced signal integrity. The connector has a gold contact finish and a height above the board of 1.004 inches (25.50mm). Each jack accommodates 8 cores, and the connector is presented in a two-row configuration. Operating temperature range is -40°C to 85°C. This component is commonly utilized in networking infrastructure, industrial automation, and telecommunications equipment.
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | Board Guide |
| Packaging | Tray |
| Connector Type | RJ45 |
| Contact Finish | Gold |
| Mounting Type | Board Edge, Through Hole |
| Shielding | Shielded, EMI Finger |
| Orientation | 90° Angle (Right) |
| Operating Temperature | -40°C ~ 85°C |
| Applications | 10/100/1000 Base-T, AutoMDIX |
| Termination | Solder |
| LED Color | Does Not Contain LED |
| Number of Cores per Jack | 8 |
| Height Above Board | 1.004"" (25.50mm) |
| Tab Direction | Up and Down |
| Contact Material | - |
| Number of Ports | 8 |
| Number of Rows | 2 |
