IQS7211A001CSR
UP TO 32 CHANNEL TRACKPAD (LIMITManufacturer: Azoteq (Pty) Ltd
Categories: Sensor, Capacitive Touch
Quality Control: Learn More
Azoteq's IQS7211A001CSR is a capacitive touch and proximity sensor IC, part of the IQ Switch® and ProxFusion® series. This 18-WLCSP (1.62x1.62) packaged component is designed for high-performance touch sensing applications. It offers up to 32 LED driver channels and 12 input channels, enabling sophisticated trackpad functionalities. The device communicates via an I2C interface and operates with a supply voltage range of 1.71V to 3.5V. Consuming only 1.32mA of current, it is suitable for power-sensitive designs. The IQS7211A001CSR is ideal for consumer electronics, automotive interiors, and industrial control panels requiring advanced human-machine interfaces. Available in Tape & Reel.
Additional Information
Series: IQ Switch®, ProxFusion®RoHS Status: unknownManufacturer Lead Time: 16 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:%20Ltd&mpn=IQS7211A001CSR&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 18-UFBGA, WLCSP |
| Mounting Type | Surface Mount |
| Interface | I2C |
| Type | Proximity Only |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 1.71V ~ 3.5V, 2.2V ~ 3.5V |
| Current - Supply | 1.32mA |
| Number of Inputs | 12 |
| Resolution | - |
| Supplier Device Package | 18-WLCSP (1.62x1.62) |
| Proximity Detection | Yes |
| LED Driver Channels | Up to 32 |
