IQS360A-0-QFR
12 CH. CAPACITIVE TRACKPAD SENSOManufacturer: Azoteq (Pty) Ltd
Categories: Sensor, Capacitive Touch
Quality Control: Learn More
Azoteq's IQS360A-0-QFR, part of the IQ Switch®, ProxSense® series, is a highly integrated capacitive sensing solution. This 32-QFN (5x5) packaged device offers 12 channels for capacitive trackpad sensing with advanced proximity detection capabilities. It supports multiple touch input types including buttons, sliders, and wheels, providing versatile user interface implementation. The IQS360A-0-QFR operates over a voltage range of 1.8V to 3.6V, drawing a minimal supply current of 360µA. Communication is facilitated via an I2C interface. Additional features include an 11-bit resolution for precise sensing and up to 8 LED driver channels for feedback or illumination. This component is commonly found in consumer electronics, automotive interfaces, and industrial control systems, all requiring robust and low-power capacitive touch functionality. The device is supplied in Tape & Reel (TR) packaging.
Additional Information
Series: IQ Switch®, ProxSense®RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:%20Ltd&mpn=IQS360A-0-QFR&lbl=1&lbc=000000&q3=1)
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 32-VFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Interface | I2C |
| Type | Buttons, Slider, Wheel |
| Operating Temperature | -20°C ~ 85°C |
| Voltage - Supply | 1.8V ~ 3.6V |
| Current - Supply | 360µA |
| Number of Inputs | 9 |
| Resolution | 11 b |
| Supplier Device Package | 32-QFN (5x5) |
| Proximity Detection | Yes |
| LED Driver Channels | Up to 8 |
| Programmable | Not Verified |
