A/SCTA2-200
Analog Current Sensor, 4-20mA, DManufacturer: Automation Components, Inc.
Categories: Current Sensors
Quality Control: Learn More
Current Sensor 100A, 200A, 250A (Selectable) 1 Channel Current Sensor Unidirectional Module
Additional Information
Series: -RoHS Status: RoHS CompliantManufacturer Lead Time: No lead time information availableProduct Status: ActivePackaging: Tape & Box (TB)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Box (TB) |
| Package / Case | Module |
| Polarization | Unidirectional |
| Sensitivity | - |
| Mounting Type | Chassis Mount |
| Output | Ratiometric, 4mA ~ 20mA |
| Frequency | 40Hz ~ 1kHz |
| Accuracy | ±1% |
| Operating Temperature | -15°C ~ 40°C |
| Voltage - Supply | 8.5V ~ 30V |
| Response Time | 600ms |
| Sensor Type | Current Sensor |
| Linearity | - |
| For Measuring | AC |
| Current - Supply (Max) | - |
| Current - Sensing | 100A, 200A, 250A (Selectable) |
| Number of Channels | 1 |
