ATSAM3N1BA-AU
IC MCU 32BIT 64KB FLASH 64LQFPManufacturer: Atmel
Categories: Microcontrollers
Quality Control: Learn More
The Atmel SAM3N series microcontroller, part number ATSAM3N1BA-AU, features an ARM Cortex-M3 32-bit single-core processor operating at 48MHz. This device offers 64KB of FLASH program memory and 8KB of RAM, along with 64KB of internal program memory. Connectivity options include I2C, IrDA, SPI, and UART/USART interfaces. Integrated peripherals include DMA, PWM, WDT, Brown-out Detect/Reset, and POR. This microcontroller includes a 10-bit, 10-channel Analog-to-Digital Converter (ADC) and a 10-bit Digital-to-Analog Converter (DAC). The ATSAM3N1BA-AU is housed in a 64-LQFP (10x10) surface-mount package and operates within a voltage range of 1.62V to 3.6V, with an operating temperature of -40°C to 85°C. Applications for this component are found in industrial automation, consumer electronics, and medical devices.
Additional Information
Series: SAM3NRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Package / Case | 64-LQFP |
| Mounting Type | Surface Mount |
| Speed | 48MHz |
| Program Memory Size | 64KB (64K x 8) |
| RAM Size | 8K x 8 |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Oscillator Type | Internal |
| Program Memory Type | FLASH |
| EEPROM Size | - |
| Core Processor | ARM® Cortex®-M3 |
| Data Converters | A/D 10x10b; D/A 1x10b |
| Core Size | 32-Bit Single-Core |
| Voltage - Supply (Vcc/Vdd) | 1.62V ~ 3.6V |
| Connectivity | I2C, IrDA, SPI, UART/USART |
| Peripherals | Brown-out Detect/Reset, DMA, POR, PWM, WDT |
| Supplier Device Package | 64-LQFP (10x10) |
| Number of I/O | 47 |
| Programmable | Not Verified |
