EM1011
MAGNETIC SWITCH LATCH 4SMTManufacturer: Asahi Kasei Microdevices/AKM
Categories: Switches (Solid State)
Quality Control: Learn More
The Asahi Kasei Microdevices/AKM EM1011 is a digital Hall effect latching switch designed for surface mount applications. This EM series component features an open collector output and operates with a supply voltage range of 3.5V to 18V, drawing a maximum of 6mA supply current and providing a maximum output current of 12mA. The device is characterized by its magnetic latching function, responding to the south pole of a magnet with a trip point of 6mT and releasing at -6mT. Packaged in a 4-SMD, Gull Wing configuration (4-SMT, Tape & Reel), the EM1011 is suitable for operation within an ambient temperature range of -30°C to 115°C. This component finds application in various industries including automotive, industrial automation, and consumer electronics, where reliable magnetic sensing and switching are critical.
Additional Information
Series: EMRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 4-SMD, Gull Wing |
| Output Type | Open Collector |
| Polarization | South Pole |
| Mounting Type | Surface Mount |
| Function | Latch |
| Operating Temperature | -30°C ~ 115°C (TA) |
| Voltage - Supply | 3.5V ~ 18V |
| Technology | Hall Effect |
| Sensing Range | 6mT Trip, -6mT Release |
| Current - Output (Max) | 12mA |
| Current - Supply (Max) | 6mA |
| Supplier Device Package | 4-SMT |
| Test Condition | 25°C |
