AK2921T
IC OPAMP ZERO-DRIFT 2CIRC 8TMSOPManufacturer: Asahi Kasei Microdevices/AKM
Categories: Instrumentation, Op Amps, Buffer Amps
Quality Control: Learn More
Asahi Kasei Microdevices/AKM AK2921T is a dual-channel zero-drift operational amplifier engineered for precision measurements. This component features an ultra-low input bias current of 20 pA and a minimal input offset voltage of 1 µV, ensuring accuracy in sensitive applications. With a gain bandwidth product of 800 kHz and a slew rate of 1 V/µs, it supports a wide range of signal conditioning tasks. The device operates from a supply voltage span of 2.7 V to 5.5 V, with a quiescent current of only 260 µA, making it suitable for power-conscious designs. This amplifier is housed in an 8-TMSOP package and is supplied on tape and reel, ideal for automated surface-mount assembly. The AK2921T finds application in industrial instrumentation, medical devices, and high-precision sensor interfaces where minimal offset drift and high accuracy are critical.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 8-TSSOP, 8-MSOP (0.110"", 2.80mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Amplifier Type | Zero-Drift |
| Operating Temperature | -40°C ~ 85°C |
| Current - Supply | 260µA |
| Slew Rate | 1V/µs |
| Gain Bandwidth Product | 800 kHz |
| Current - Input Bias | 20 pA |
| Voltage - Input Offset | 1 µV |
| Supplier Device Package | 8-TMSOP |
| Number of Circuits | 2 |
| Current - Output / Channel | 35 mA |
| Voltage - Supply Span (Min) | 2.7 V |
| Voltage - Supply Span (Max) | 5.5 V |
