AP1023AEN
IC HALF BRIDGE DRVR 1.45A 24QFNManufacturer: Asahi Kasei Microdevices/AKM
Categories: Full Half-Bridge (H Bridge) Drivers
Quality Control: Learn More
The Asahi Kasei Microdevices/AKM AP1023AEN is a general-purpose half-bridge driver designed for driving stepper motors and power MOSFETs. This component utilizes Power MOSFET technology and is housed in a 24-QFN (4x4) exposed pad package, suitable for surface mount applications. It features a logic interface and an output configuration of a half bridge, capable of delivering 1.45A per channel. The AP1023AEN offers fault protection including over-temperature and UVLO, operating within a load voltage range of 1.6V to 6.5V and a supply voltage range of 2.7V to 5.5V. Its operating temperature spans from -40°C to 150°C (TJ). This device is commonly employed in general-purpose applications and stepper motor control systems. The component is supplied on a tape and reel.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: 18 week(s)Product Status: Not For New DesignsPackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Features | - |
| Packaging | Tape & Reel (TR) |
| Package / Case | 24-WFQFN Exposed Pad |
| Mounting Type | Surface Mount |
| Interface | Logic |
| Operating Temperature | -40°C ~ 150°C (TJ) |
| Output Configuration | Half Bridge (4) |
| Voltage - Supply | 2.7V ~ 5.5V |
| Rds On (Typ) | - |
| Applications | General Purpose, Stepper Motors |
| Current - Output / Channel | 1.45A |
| Current - Peak Output | - |
| Technology | Power MOSFET |
| Voltage - Load | 1.6V ~ 6.5V |
| Supplier Device Package | 24-QFN (4x4) |
| Fault Protection | Over Temperature, UVLO |
| Load Type | Inductive |
