APSDM032GM4AN-6BTM
SSD 32GB MSATA MLC SATA III 3.3VManufacturer: Apacer Memory America
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Apacer Memory America APSDM032GM4AN-6BTM is a 32GB mSATA Solid State Drive (SSD) utilizing MLC NAND flash memory. This component adheres to the SATA III interface standard, operating at a 3.3V supply voltage with a typical current consumption of 320mA. Measuring 50.80mm x 29.85mm x 3.80mm, it offers a compact mSATA form factor. Sequential read speeds reach up to 375MB/s, while sequential write speeds are rated at 100MB/s. The operating temperature range for this device is 0°C to 70°C. This drive is suitable for applications in industrial automation, embedded systems, and networking equipment.
Additional Information
Series: mSATA A1-MRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Size / Dimension | 50.80mm x 29.85mm x 3.80mm |
| Memory Size | 32GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (MLC) |
| Type | SATA III |
| Weight | - |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3.3V |
| Current - Max | 320mA (Typ) |
| Form Factor | mSATA |
| Speed - Read | 375MB/s |
| Speed - Write | 100MB/s |
