APSDM001GS3AN-AT
SSD 1GB SATA DOM SLC SATAIII 5VManufacturer: Apacer Memory America
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Apacer Memory America’s SDM5 7P/180D Slim2 series APSDM001GS3AN-AT is a 1GB SLC NAND Solid State Drive Disk-On-Module. This SATA III interface device operates at 5V, consuming a typical maximum current of 125mA. Its compact form factor measures 17.00mm x 40.00mm x 6.10mm. The drive offers sequential read speeds of up to 37MB/s and write speeds of up to 14MB/s. This component is suitable for industrial applications requiring high endurance and reliable data storage, including embedded systems and industrial automation. The APSDM001GS3AN-AT is supplied in bulk packaging.
Additional Information
Series: SDM5 7P/180D Slim2RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Size / Dimension | 17.00mm x 40.00mm x 6.10mm |
| Memory Size | 1Gb |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (SLC) |
| Type | SATA III |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 5V |
| Current - Max | 125mA (Typ) |
| Form Factor | Disk-On-Module, SATA DOM |
| Speed - Read | 37MB/s |
| Speed - Write | 14MB/s |
