APM2T42SM22256GFN-4FTMG
SSD 256GB M.2 MLC SATA III 3.3VManufacturer: Apacer Memory America
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Apacer Memory America SM220-M242 series APM2T42SM22256GFN-4FTMG is a 256GB M.2 SATA III solid-state drive utilizing MLC NAND flash memory. This module operates at 3.3V with a maximum current draw of 750mA. Featuring a compact M.2 2242 form factor (42.00mm x 22.00mm x 3.50mm), it offers sequential read speeds up to 525MB/s and sequential write speeds up to 355MB/s. The operating temperature range is 0°C to 70°C. This component is suitable for applications in industrial computing, embedded systems, and data acquisition.
Additional Information
Series: SM220-M242RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Size / Dimension | 42.00mm x 22.00mm x 3.50mm |
| Memory Size | 256GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (MLC) |
| Type | SATA III |
| Operating Temperature | 0°C ~ 70°C |
| Voltage - Supply | 3.3V |
| Current - Max | 750mA |
| Form Factor | M.2 Module |
| Speed - Read | 525MB/s |
| Speed - Write | 355MB/s |
