APM128GNEAN-4ETM1GW
SSD 128GB MSATA MLC SATAIII 3.3VManufacturer: Apacer Memory America
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Apacer Memory America APM128GNEAN-4ETM1GW is a 128GB MLC NAND SATA III mSATA Solid State Drive from the SM220-300B series. This component offers read speeds up to 260MB/s and write speeds up to 180MB/s, operating at a supply voltage of 3.3V with a maximum current draw of 490mA. Its mSATA form factor, measuring 29.85mm x 26.80mm x 3.95mm, makes it suitable for compact designs. The APM128GNEAN-4ETM1GW is engineered for reliability with an extended operating temperature range of -40°C to 85°C. This drive is commonly utilized in industrial computing, embedded systems, and networking equipment. It is supplied in tray packaging.
Additional Information
Series: SM220-300BRoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: DiscontinuedPackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Size / Dimension | 29.85mm x 26.80mm x 3.95mm |
| Memory Size | 128GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (MLC) |
| Type | SATA III |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 3.3V |
| Current - Max | 490mA |
| Form Factor | mSATA |
| Speed - Read | 260MB/s |
| Speed - Write | 180MB/s |
