AP-UM016GAU0ES-2T
SSD 16GB EUSB MODULE SLC 5VManufacturer: Apacer Memory America
Categories: Solid State Drives (SSDs), Hard Disk Drives (HDDs)
Quality Control: Learn More
Apacer Memory America's AP-UM016GAU0ES-2T is a 16GB Solid State Drive (SSD) featuring Single-Level Cell (SLC) NAND flash technology. This Disk-On-Module, eUSB form factor component operates at a 5V supply voltage with a typical current consumption of 150mA. Measuring 24.00mm x 17.90mm x 5.00mm, it offers read speeds of up to 40MB/s and write speeds of up to 35MB/s. The module is designed for robust operation within an industrial temperature range of -40°C to 85°C. This component is suitable for embedded systems, industrial automation, and networking applications requiring reliable, high-endurance storage. Packaged in trays, it provides a compact and durable storage solution for demanding environments.
Additional Information
Series: -RoHS Status: ROHS3 CompliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tray |
| Size / Dimension | 24.00mm x 17.90mm x 5.00mm |
| Memory Size | 16GB |
| Memory Type | Solid State Drive (SSD) FLASH - NAND (SLC) |
| Type | - |
| Operating Temperature | -40°C ~ 85°C |
| Voltage - Supply | 5V |
| Current - Max | 150mA (Typ) |
| Form Factor | Disk-On-Module, eUSB |
| Speed - Read | 40MB/s |
| Speed - Write | 35MB/s |
