AD9502CM
PROGRAMMABLE DELAY GENERATORManufacturer: Analog Devices Inc.
Categories: Video Processing
Quality Control: Learn More
Analog Devices Inc. AD9502CM is a versatile video digitizer IC designed for NTSC, PAL, and RS-170 video standards. This through-hole component is housed in a 40-CDIP package, measuring 0.900 inches. Its primary function is to digitize video signals, making it suitable for applications in consumer video systems. The device operates within a supply voltage range of 4.75V to 5.25V. This component is offered in bulk packaging.
Additional Information
Series: -RoHS Status: RoHS non-compliantManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: BulkDatasheet:Download Free CAD Model:
Technical Details:
| Packaging | Bulk |
| Package / Case | 40-CDIP (0.900"", 22.86mm) |
| Mounting Type | Through Hole |
| Function | Video Digitizer |
| Voltage - Supply | 4.75V ~ 5.25V |
| Applications | Consumer Video |
| Standards | NTSC, PAL, RS-170 |
| Supplier Device Package | 40-CDIP |
| Control Interface | - |
Request a Quote
