AD813AR-14-REEL7
IC AMP CURRENT FEEDBACK 14SOICManufacturer: Analog Devices Inc.
Categories: Video Amps and Modules
Quality Control: Learn More
Analog Devices Inc. AD813AR-14-REEL7 is a triple, current-feedback operational amplifier designed for high-speed video signal processing. This component offers a -3dB bandwidth of 100 MHz and a rapid slew rate of 250V/µs, facilitating accurate amplification of video signals. The device operates with a low quiescent current of 4.5 mA and can deliver an output current of 50 mA per channel. It supports a wide supply voltage range, accommodating single supplies from 2.4V to 36V or dual supplies from ±1.2V to ±18V. The AD813AR-14-REEL7 is packaged in a 14-SOIC (0.154" width) on a tape and reel for automated surface mounting. This amplifier is suitable for applications in broadcast video, high-resolution monitor drivers, and other demanding signal conditioning circuits.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | 14-SOIC (0.154"", 3.90mm Width) |
| Output Type | - |
| Mounting Type | Surface Mount |
| Applications | Current Feedback |
| Slew Rate | 250V/µs |
| Voltage - Supply, Single/Dual (±) | 2.4V ~ 36V, ±1.2V ~ 18V |
| Supplier Device Package | 14-SOIC |
| Number of Circuits | 3 |
| Current - Supply | 4.5 mA |
| Current - Output / Channel | 50 mA |
| -3db Bandwidth | 100 MHz |
