ADM811-3TARTZ-RL
IC SUPERVISOR 1 CHANNEL SOT143-4Manufacturer: Analog Devices Inc.
Categories: Supervisors
Quality Control: Learn More
Analog Devices Inc. ADM811-3TARTZ-RL is a supervisor IC featuring a push-pull, totem pole output. This component is designed for single-channel voltage monitoring with a threshold setting of 3.08V. The reset function is active low with a minimum timeout of 140ms. Operating across a temperature range of -40°C to 85°C (TA), the ADM811-3TARTZ-RL is provided in a SOT-143-4 package, also identified as TO-253-4 or TO-253AA, suitable for surface mount applications. The component is supplied on tape and reel, ensuring efficient handling in high-volume manufacturing. Its functionality makes it suitable for applications in industrial control systems, consumer electronics, and automotive electronics where reliable power-on reset and voltage supervision are critical.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Tape & Reel (TR)Datasheet:Download Free CAD Model:
Technical Details:
| Packaging | Tape & Reel (TR) |
| Package / Case | TO-253-4, TO-253AA |
| Mounting Type | Surface Mount |
| Output | Push-Pull, Totem Pole |
| Type | Simple Reset/Power-On Reset |
| Reset | Active Low |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Number of Voltages Monitored | 1 |
| Reset Timeout | 140ms Minimum |
| Voltage - Threshold | 3.08V |
| Supplier Device Package | SOT-143-4 |
| Programmable | Not Verified |
