AD8193ACPZ
IC SWITCH TMDS BUFF 2:1 32LFCSPManufacturer: Analog Devices Inc.
Categories: Special Purpose
Quality Control: Learn More
Analog Devices Inc. AD8193ACPZ is a 4-channel, 2:1 multiplexer/demultiplexer IC designed for high-speed video signal routing. This TMDS buffer supports HDMI and DVI interfaces, offering a 3V to 3.6V single supply operation. The AD8193ACPZ is housed in a compact 32-LFCSP (5x5) package, suitable for surface mount applications. Its buffered architecture ensures signal integrity across its operating temperature range of -40°C to 85°C. This component is widely utilized in video distribution systems, display interfaces, and professional AV equipment.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: TrayDatasheet:Download Free CAD Model:
Technical Details:
| Features | TMDS, HDMI, DVI, Buffered |
| Packaging | Tray |
| Package / Case | 32-VFQFN Exposed Pad, CSP |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Video |
| On-State Resistance (Max) | - |
| -3db Bandwidth | - |
| Supplier Device Package | 32-LFCSP (5x5) |
| Voltage - Supply, Single (V+) | 3V ~ 3.6V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | - |
| Multiplexer/Demultiplexer Circuit | 2:1 |
| Number of Channels | 4 |
