AD8186ARUZ-RL
IC MULTIPLEXER TRPL 2X1 24TSSOPManufacturer: Analog Devices Inc.
Categories: Special Purpose
Quality Control: Learn More
Analog Devices Inc. AD8186ARUZ-RL is a triple 2x1 multiplexer, specifically a video switch IC, housed in a 24-TSSOP package. This component offers a 480MHz -3dB bandwidth, making it suitable for high-speed video applications. It features buffered outputs and supports RGB signals. The AD8186ARUZ-RL is designed for surface mount installation and operates from a single 3.5V to 5.5V supply. Its triple SPDT switch configuration allows for flexible signal routing. This device finds application in video processing systems and broadcast equipment. The component is supplied in cut tape packaging.
Additional Information
Series: -RoHS Status: unknownManufacturer Lead Time: No lead time information availableProduct Status: ObsoletePackaging: Cut Tape (CT)Datasheet:Download Free CAD Model:
Technical Details:
| Features | Buffered, RGB |
| Packaging | Cut Tape (CT) |
| Package / Case | 24-TSSOP (0.173"", 4.40mm Width) |
| Mounting Type | Surface Mount |
| Operating Temperature | -40°C ~ 85°C (TA) |
| Applications | Video |
| On-State Resistance (Max) | - |
| -3db Bandwidth | 480MHz |
| Supplier Device Package | 24-TSSOP |
| Voltage - Supply, Single (V+) | 3.5V ~ 5.5V |
| Voltage - Supply, Dual (V±) | - |
| Switch Circuit | SPDT |
| Multiplexer/Demultiplexer Circuit | 2:1 |
